BOPA Film from 12 to 30 Microns

Product Description: ULTRANY® OA-Customised Model BOPA Film (12 to 30μm)

BOPA Film from 12 to 30 Micron model ULTRANY OA-customised offers a complete array of BOPA film thicknesses to meet virtually every unique industrial need. Utilising advanced two-step biaxial orientation, BOPA Film from 12 to 30 microns allows customers to choose either a 12 micron ultra-thin BOPA film to optimise costs or a 20 to 30 micron heavy-duty BOPA film to maximise protection. The ability to customise the thickness of BOPA film allows BOPA Film from 12 to 30 microns to be used as a universal BOPA film for all food packaging applications -- from light-weight snack packaging to bulk frozen meat packaging.

Ultra-thin BOPA Film (12 micron)

The 12 micron ultra-thin BOPA film in this series sets a new standard for source reduction and lightweight packaging. In spite of being thinner than previous versions of BOPA film, this ultra-thin BOPA Film from 12 to 30 microns retains the core mechanical strength and robust oxygen barrier that are fundamental to BOPA film's performance. Due to having more linear meters per roll than other versions of BOPA film, BOPA Film from 12 to 30 microns will improve productivity. Therefore, the ultra-thin version of BOPA Film from 12 to 30 microns is suitable for dry snack packaging, powdered seasoning packaging, and puffed food packaging, where the primary focus is on thinning down materials.

Heavy-Duty BOPA Film (20 to 30 micron)

For applications requiring greater physical resistance, the 20 to 30 micron heavy-duty BOPA film options provide fortress-level protection. The 30 micron version of BOPA Film from 12 to 30 microns provides a 20N puncture resistance level that is essential for packaging frozen whole fish or hard-shell nuts. The custom thickness BOPA film range has single-side corona treatments to enable easy printing and laminating. With a massive production capacity of 150,000 tons per year, BOPA Film from 12 to 30 microns enables a sustainable packaging approach by significantly reducing food waste due to superior durability and high-performance barrier properties.

BOPA Film from 12 to 30 Microns

12 micron ultra-thin BOPA film

custom thickness BOPA film

20 to 30 microns heavy-duty BOPA film

Benefits of OA-customised model BOPA film (ULTRANY®) 12 to 30μm

a. High-performance source reduction at the 12 micron end of the spectrum enables brands to achieve cost savings while maintaining barrier integrity.

b. Maximum protection at the 30 micron end of the spectrum offers up to 20N puncture resistance for the most difficult-to-package products with sharp edges.

c. Excellent oxygen barrier properties across the entire range protect high-value products from oxidative spoilage and flavour loss.
d. High definition printing capabilities provided by corona-treated surfaces enable high-quality branding graphics for all packaging configurations.
e. The wide variety of thickness levels available in the BOPA film range enables brands to match their packaging needs to the performance required for their contents.

Thickness μm	Corona	Width mm
12/20/25/30	One Side	300-1500

Basic Info.

ULTRANY® OA-customised model BOPA Film for food applications:

• Dry snacks and puffed foods are packaged in 12 micron ultra-thin BOPA film to minimise packaging usage and shipping weight.

• Bone-in poultry and heavy seafood are packaged in 20 to 30 micron heavy-duty BOPA film to protect against punctures caused by sharp edges.

• Custom thickness BOPA film bags for bulk cereal and coffee beans to assure mechanical stability during shipment and storage.

• Artisan frozen vegetable and dough packaging using BOPA film for all food packaging applications to maintain flexibility when stored at below freezing temperatures.

• Packaging powdered spices and seasonings in the 12 micron ultra-thin version of BOPA film for its high-speed processing and aromatic barrier properties.

BOPA Film from 12 to 30 Microns

BOPA film for all food packaging

BOPA Film from 12 to 30 Microns

BOPA Film from 12 to 30 Microns

ULTRANY® OA-customised BOPA Film can also be utilised for:

• Large volume pet food bags require 20 to 30 micron heavy-duty BOPA film for high burst strength and grease resistance.

• Industrial metal parts and hardware packaging using 30 micron custom thickness BOPA film to resist friction and damage from sharp protrusions.

• Sterile medical supply pouches are packaged using BOPA film for all food packaging applications to maintain a sterile, oxygen-free environment.

• Liquid e-commerce shipping liners require the high tensile strength of film for packaging and protecting the liquids inside.

Product Parameters

Length (m): Standard 4000 ~ 24000
With(mm): 300-1500
Paper core (inches): 3, 6

Packaging: 9, 4 or 2 rolls/pallet

Remark:

1. We publish this data to offer a helpful and trustworthy viewpoint of normal film performance. This data should only be utilised as a reference point. As we continue to advance innovative technologies, Changsu reserves the right to alter product specifications at any time without prior notification.

2. Would you like me to provide a comparison chart detailing the yield (meters per kilogram) of the 12 micron film versus the standard 15 micron film?

How do I determine what thickness is best for my specific product?

The selection process is dependent upon the type of physical stresses that occur. To save money and create dry snack packaging, choose the 12 micron ultra-thin BOPA film. For most applications requiring regular food packaging, the 15-25 micron custom thickness BOPA film is the best option. For the greatest amount of physical challenge, such as packaging bone-in poultry, choose the 20 to 30 micron heavy-duty BOPA film for ultimate protection.

Why is this film better for packaging aluminium foil structures?

Aluminium foil is very difficult to bond; however, the high-energy surface of BOPA Film for Retort Pouch creates a superior composite layer. This dual-treated BOPA film, as a core layer for a retort pouch, eliminates delamination failures between the foil and other layers, which are common failures for single-sided treated films.

Will BOPA Film from 12 to 30 Micron perform well with frozen, sharp seafood?

Yes, the OA-30µm model is designed for this application. The 20 to 30 micron heavy-duty BOPA film provides a 20N puncture resistance level and exceptional toughness, acting as a fortress for the most difficult-to-pack products with sharp edges, and preventing rapture.

What are the printing advantages of the customised BOPA film range?

Each of the BOPA film options in the customised BOPA film range has single-side corona treatment and a high-energy surface of 54 mN/m to assure excellent ink adhesion and create high-definition branding graphics regardless of whether using 12 micron ultra-thin BOPA film or 20 to 30 micron heavy-duty BOPA film.

How does BOPA Film from 12 to 30 Micron contribute to global sustainability trends?

BOPA Film from 12 to 30 Micron contributes to the circular economy in two ways. The 12 micron ultra-thin BOPA film provides source reduction. Additionally, the 20 to 30 micron heavy-duty BOPA film minimises packaging failures and food waste. These results clearly demonstrate how custom thickness BOPA film can provide a critical element for companies working towards sustainability.

Service Advantages

1

Stable Global Supply Chain

Guarantees the availability of inventory for global customers with high demand by producing over 150,000 tons of BOPA film per year and having strategically located production facilities around the world.

2

Professional Technical Support Available 24 hours/365 days:

Provides customer technical support 24/7 to assist in selecting the correct thickness for your specific packaging challenges.

3

Rapid Prototyping and Customisation:

Enables the rapid development of customised thickness BOPA film models based on the unique barrier and mechanical requirements of each customer.
